Hashmi Sheets and Plates is a trusted manufacturer and supplier of Stainless Steel 17-7 PH Channels in Doha, Qatar, delivering high-performance materials for demanding engineering applications. Known for their exceptional strength and reliability, these channels are produced using precipitation-hardening stainless steel that offers an excellent balance of corrosion resistance and mechanical performance. Stainless Steel 17-7 PH channels are valued for their dimensional stability, precision, and ability to perform under high stress. With strict quality control and timely delivery, Hashmi Sheets and Plates supports industries that require dependable and long-lasting stainless steel solutions.
Stainless Steel 17-7 PH Channel is a precipitation-hardening alloy composed of approximately 16-18% chromium, 6.5-7.75% nickel, 0.75-1.5% aluminum, and trace amounts of manganese (1% max), silicon (1% max), and carbon (0.09% max). This composition delivers excellent corrosion resistance and high strength. The alloy has a tensile strength of 1035-1400 MPa and a yield strength of 865-1170 MPa, with elongation ranging from 5-10%. Its hardness varies from 38-45 HRC, depending on heat treatment. Stainless Steel 17-7 PH offers remarkable fatigue resistance, making it ideal for demanding structural and industrial applications.
| Standard | ASTM A240 / ASME SA240, ASTM A276 / A182, ASTM A479 – AL-6XN, A286 |
| Width | 1000mm-2000mm |
| Thickness | 1.0mm – 100mm |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coil, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Element | 17-7PH |
| Carbon | 0.09 |
| Chromium | 16.0-18.0 |
| Nickel | 6.5-7.7 |
| Manganese | 1.00 |
| Silicon | 1.00 |
| Aluminum | 0.75-1.50 |
| Phosphorus | 0.040 |
| Sulfur | 0.030 |
| Property | 17-7PH ≤ 0.010 inch thick | 17-7PH > 0.010 inch thick |
| Yield Strength, min. (ksi) | 65 | 55 |
| Tensile Strength, min. (ksi) | 150 | 150 |
| Elongation, min. (%) | – | 20 |
| Hardness, max. (Rb) | – | 92 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hashmi Sheets and Plates based in Doha, Qatar, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless Steel 17-7 PH channels are composed mainly of iron, chromium, nickel, and aluminum, with controlled carbon content. This unique composition allows the material to be precipitation hardened, resulting in very high tensile and yield strength. These channels exhibit excellent fatigue resistance, good corrosion resistance, and impressive dimensional stability. They maintain strength at elevated temperatures and offer good formability in the annealed condition. After heat treatment, SS 17-7 PH channels achieve superior hardness and load-bearing capability.
Yes, we offer custom sizes for Stainless Steel 17-7 PH Channel to meet specific project needs. Our team at Hashmi Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Stainless Steel 17-7 PH channels are widely used in applications that demand high strength, precision, and durability. Common uses include aerospace components, structural supports, spring housings, and high-stress industrial frameworks. They are also used in chemical processing equipment, power generation systems, and specialized mechanical assemblies. Due to their excellent fatigue resistance and corrosion performance, these channels are suitable for environments involving repeated loading and harsh conditions. SS 17-7 PH channels are ideal for projects where lightweight strength and long-term reliability are essential.
